What is a Heavy Copper PCB?
Heavy copper PCB solutions are designed for high-current and power electronic applications requiring enhanced conductivity and thermal performance. By using thicker copper layers than standard circuit boards, these PCBs provide improved current capacity, heat dissipation, and mechanical reliability. YSX Electronics offers customized heavy copper PCB manufacturing with precise copper weight control, advanced layer structures, and reliable production capabilities for applications such as power supplies, automotive systems, industrial equipment, and energy devices.
Advanced Heavy Copper PCB Technologies
Special manufacturing techniques ensure performance and reliability in high-power designs.
- Hybrid Stack-up → Combine signal & power layers
- Copper Inlay / Embedded Copper → Enhanced heat transfer
- Thermal Vias → Efficient heat dissipation
- Heavy Copper Plating → Increased current capacity
Key Advantages of Heavy Copper PCB
Heavy Copper PCBs are optimized for power handling, thermal management, and durability.
- High Current Carrying Capacity → Supports high-power circuits
- Excellent Heat Dissipation → Improves thermal management
- Enhanced Mechanical Strength → Stronger connectors & vias
- Improved Reliability → Reduced failure risk in harsh environments
- Compact High-Power Design → Enables smaller product size
Challenges in Heavy Copper PCB Design
| Challenge | YSX Solution |
| Difficult etching of thick copper | Precision etching process control |
| Wide trace requirement | Optimized layout design support |
| Heat concentration | Thermal via & copper balancing |
| Mechanical stress | Reinforced structure design |
| High cost risk | DFM optimization & cost control |
Our Heavy Copper PCB Capabilities
| Capability Category | YSX Capability |
|---|---|
| Layer Count | 1–20 layers |
| Copper Thickness | 2oz – 10oz+ |
| Board Thickness | 0.4mm – 6.0mm |
| Materials | FR4, High-TG, metal core |
| Min Trace / Space | 4/4 mil (depends on copper weight) |
| Min Hole Size | 0.15mm |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver |
| Via Types | Through-hole, filled vias |
| Special Processes | Copper inlay, thermal vias |
| Production | Prototype to mass production |
Heavy Copper PCB vs Standard PCB
| Feature | Standard PCB | Thick Copper PCB |
|---|---|---|
| Copper Thickness | 1–2 oz | ≥4 oz |
| Current Capacity | Low | High |
| Heat Dissipation | Moderate | Excellent |
| Mechanical Strength | Standard | High |
| Cost | Lower | Higher |
| Application | General electronics | Power electronics |
